112 U1253B User’s and Service Guide
4 Changing the Default Settings
For another example, when you turn the rotary switch to
the position, the initial measurement range is Auto
according to default factory setting. In order to choose a
different range, you will have to press the button.
If you prefer to have a different set of initial measurement
functions, change the M- INITIAL setting to USER, and press
the button. The multimeter will then enter the INIT
pages. Please refer to Figure 4- 25.
Figure 4-25 Setting initial measurement functions
In the INIT pages, you may define your preferred initial
measurement functions. Please refer to Figure 4- 26.
Press or to navigate between the two INIT pages.
Press or to choose which initial function you want to
change.
to switch between
FACTORY and USER
Press or
Press Hz
to edit
Press Hz to save
and exit
If USER
is selected
If FACTORY
is selected
to INIT pages
initial measurement
for setting up
Press Hz to proceed
To Next Page
