138 U1253B User’s and Service Guide
6 Performance Tests and Calibration
Recommended Test Equipment
The test equipment recommended for the performance
verification and adjustment procedures is listed below. If the
exact instrument is not available, substitute with another
calibration standard of equivalent accuracy.
A suggested alternative method would be to use the Agilent
3458A 8½ – Digit Digital Multimeter to measure less
accurate yet stable sources. The output value measured from
the source can be entered into the instrument as the target
calibration value.
Table 6-1 Recommended test equipment
Application Recommended equipment
Recommended accuracy
requirements
DC voltage Fluke 5520A < 20% of U1253B accuracy spec
DC current Fluke 5520A < 20% of U1253B accuracy spec
Resistance Fluke 5520A < 20% of U1253B accuracy spec
AC voltage Fluke 5520A < 20% of U1253B accuracy spec
AC current Fluke 5520A < 20% of U1253B accuracy spec
Frequency Agilent 33250A < 20% of U1253B accuracy spec
Capacitance Fluke 5520A < 20% of U1253B accuracy spec
Duty cycle Fluke 5520A < 20% of U1253B accuracy spec
Nanosiemens Fluke 5520A < 20% of U1253B accuracy spec
Diode Fluke 5520A < 20% of U1253B accuracy spec
Frequency counter Agilent 33250A < 20% of U1253B accuracy spec
Temperature Fluke 5520A < 20% of U1253B accuracy spec
Square wave Agilent 53131A and Agilent 34401A < 20% of U1253B accuracy spec
Short
Shorting plug - dual banana plug with
copper wire shorting the 2 terminals
–
Battery level Fluke 5520A < 20% of U1253B accuracy spec
