20 U1253B User’s and Service Guide
1Getting Started
Selecting display with the Shift button
The table below shows the primary display selection, with
respect to measurement function (rotary switch position),
using the Shift button.
Table 1-7 Selecting display with the Shift button
Rotary switch position (Function) Primary display
(AC voltage)
AC V
dBm or dBV (in dual display mode)
[1] [2]
(AC+DC voltage)
DC V
AC V
AC+DC V
(AC+DC voltage)
DC mV
AC mV
AC+DC mV
(Resistance)
Ω
Ω (Audible)
nS
(Diode Test & Frequency)
Diode
Hz
(Capacitance & Temperature)
Capacitance
Te m p e r a t u r e
(AC+DC current)
DC μA
AC μA
AC+DC μA
