Agilent Technologies U1253B

194 U1253B User’s and Service Guide
7 Specifications
Input impedance
Table 7-17 Input Impedance
Function Range Input Impedance
DC Voltage
[1][3]
50.000 mV 10.00 MΩ
500.00 mV 10.00 MΩ
1000.0 mV 10.00 MΩ
5.0000 V 11.10 MΩ
50.000 V 10.10 MΩ
500.00 V 10.01 MΩ
1000.0 V 10.001 MΩ
AC Voltage
[2]
50.000 mV 10.00 MΩ
500.00 mV 10.00 MΩ
1000.0 mV 10.00 MΩ
5.0000 V 10.00 MΩ
50.000 V 10.00 MΩ
500.00 V 10.00 MΩ
1000.0 V 10.00 MΩ
