136
U1253B User’s and Service Guide
5M
a
i
n
t
e
n
a
n
c
e
Figure 5-9
Fuse replacement
Ta
b
l
e
5
-
4
Fuse specifications
Fuse
Agilent part number
Rating
Size
Ty
p
e
1
2
110-1400
440 mA/1000 V
10 mm × 35 mm
Fast blow fuse
2
2
110-1402
11 A/1000 V
10 mm × 38 mm
Fuse 1
Fuse 2
157
159
