Making Measurements 2
U1253B User’s and Service Guide 33
Measuring Current
µA and mA measurement
Set up your multimeter to measure µA and mA as shown in
Figure 2- 3. Probe the test and read the display.
• Press if necessary to ensure is shown on the display.
• For μA measurement, set the rotary switch to , and connect
the positive test lead to μA.mA.
• For mA measurement, set the rotary switch to , and
connect the positive test lead to μA.mA.
• For A (ampere) measurement, set the rotary switch to ,
and connect the positive test lead to A.
• Press to display dual measurements. See Tab l e 1 - 8 of “Selecting
display with the Dual button” on page 21 for a list of dual
measurements available.
• Press and hold for more than 1 second to exit dual display mode.
