43
Chapter 3: Installation
VSpin User Guide
4. Manually turn the rotor slightly so that the left side of the bucket
lightly touches the gripper.
5. Click Capture 1.
6. Turn the rotor slightly so that the right side of the bucket lightly
touches the gripper.
7. Click
Capture 2.
8. Turn on the air source to the VSpin.
9. Click
OK.
The new teachpoint is listed on the
Profiles screen.
10. Remove the gripper from the VSpin door.
If you do not remove the gripper, it obstructs the closing of the door.
.
