Chapter 2: VSpin Overview
VSpin User Guide
18
About the Diagnostics Page
Overview The Diagnostics page helps you diagnose problems quickly by providing
you with the controls and VSpin status information shown in the
screen shot below.
Diagnostics Page
Procedures
The following procedures are performed from the Diagnostics page.
Function Procedure
Checking the spin status:
❑ Status lights, which provide the same
information as the status lights on the Control
page, excluding Door closed.
❑ Current bucket position
❑ Current home position
“Monitoring the Progress
of a Spin” on page 61
