K65C/K75C/K95C
4-1
K65C/K75C/K95C
4-1
15 14 13 12 11
1 2 3 4 5 6 7 8 9 10
15 14 13 12 11
1 2 3 4 5 6 7 8 9 10
4 Description
4.1 Overview
1 - Bucket protection
2 - Bucket/attachment
3 - Tip rod
4 - Tip lever
5 - Pivot arm
6 - Bucket arm
7 - Tip cylinder
8 - Fuel tank (right-hand side of vehicle)
9 - Driver's cabin
10 - Drive motor
11 - Rear axle
12 - Hydraulic oil reservoir
13 - Articulation pivot joint
14 - Front axle
15 - Quick-change device
Figure 4-1
4 Description
4.1 Overview
1 - Bucket protection
2 - Bucket/attachment
3 - Tip rod
4 - Tip lever
5 - Pivot arm
6 - Bucket arm
7 - Tip cylinder
8 - Fuel tank (right-hand side of vehicle)
9 - Driver's cabin
10 - Drive motor
11 - Rear axle
12 - Hydraulic oil reservoir
13 - Articulation pivot joint
14 - Front axle
15 - Quick-change device
Figure 4-1
