K65C/K75C/K95C
7-7
K65C/K75C/K95C
7-7
-
The max. permissible load of the
shunting and towing coupling
(7-2/2) is 4.5 t horizontally in
the longitudinal direction.
- The max. permissible load of
the lashing points/load-bearing
points (7-2/1 and 7-6/1) is 2.0 t
at an assumed bracing angle
of 45°.
7.2 Lifting by crane
The loader to be lifted must be
prepared as follows:
(1) Set the drive switch (4-12/6) to
position "0".
(2) Set transmission stage "I"
(4-13/13) (only for fast loaders -
» 30 km/h «.
(3) Set hydraulic drive stage "I"
(4-12/7).
(4) Apply the parking brake
(4-12/3).
(5) Lift or lower the bucket arm
until the lowest point of the bucket
arm or of the bucket is at least
30 cm above the road (5-2).
(6) Close the ball block valve for
the working and auxiliary hy-
draulics (1-3/arrow).
(7) Lock the doors.
(8) Fold the outside mirror
inwards.
-
The max. permissible load of the
shunting and towing coupling
(7-2/2) is 4.5 t horizontally in
the longitudinal direction.
- The max. permissible load of
the lashing points/load-bearing
points (7-2/1 and 7-6/1) is 2.0 t
at an assumed bracing angle
of 45°.
7.2 Lifting by crane
The loader to be lifted must be
prepared as follows:
(1) Set the drive switch (4-12/6) to
position "0".
(2) Set transmission stage "I"
(4-13/13) (only for fast loaders -
» 30 km/h «.
(3) Set hydraulic drive stage "I"
(4-12/7).
(4) Apply the parking brake
(4-12/3).
(5) Lift or lower the bucket arm
until the lowest point of the bucket
arm or of the bucket is at least
30 cm above the road (5-2).
(6) Close the ball block valve for
the working and auxiliary hy-
draulics (1-3/arrow).
(7) Lock the doors.
(8) Fold the outside mirror
inwards.
