Accessories
8AL91446ENAA ed02 99 /113
5.5.3.1 Remove the customization kit
A
B
C
1
Slide your fingernail along
the piece to detach it from
the phone.
This piece is clipped to the four
corners. We recommend starting
from the back of the desk phone.
Carefully insert a thin, non-sharp
object over the colored piece on
left side.
Press, then slide the
piece towards the
bottom of the device a
few millimeters with
your thumbs.
2
Pull perpendicular to the
desk phone along the
entire length of the piece.
Be careful not to break the
clips.
Gently lift the piece by pushing
forward (you will hear a small
click when the piece is removed).
Remove the piece by
lifting it.
Be careful not to break
the clips.
3
Insert the thin, non-sharp object
on the right side.
4
Gently lift the piece by pushing
forward (you will hear a small
click when the piece is removed).
5
Remove the piece by rotating it as
shown in the drawing.
5.5.3.2 Install the customization kit
A
B
C
1
Place each clip facing the
corresponding notches. Be
careful to place the piece in
the correct direction: the
logo must be on the right
hand side.
Insert the piece around the
speaker of the station.
Press as shown in the drawing to
clip the piece in the front (you
should hear a small click when
the clip is in its notch).
Place the piece by
respecting the notches.
2
Press perpendicular to the
desk phone all along the
piece. Press gently so as
not to force and break a
clip.
Push the piece by slight rotation
until it is in its place.
Slide the piece to the
top of the handset a few
millimeters with your
thumbs.
3
Press as shown in the drawing to
clip the piece in the back (you
should hear a small click when
the clip is in its notch).
