The RPM curve shows data from a TM Mini 60cc engine with the engine setting set to TM
Mini 60cc. As can be seen from the RPM curve, Alfano 7, knowing the type of engine in use,
was able to recognize the discontinuities generated by the limiter, hiding its intervention
and consequently the start and end points
EXAMPLE - RPM curve with standard engine type setting
The RPM curve shows data from a TM Mini 60cc engine with standard engine setting. As can
be seen from the RPM curve the limiter generated downward peaks during the intervention
period
The starting and ending points of intervention of the engine speed limiter are highlighted
Start of limiter
intervention
End of limiter
intervention
EXAMPLE - RPM curve with TM Mini 60cc engine type setting
35
8. Settings
8.2.4. RPM
8.2. Alfano 7 Settings, Connected Sensors and Boxes
