Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 65
Connector Data and Feature Descriptions Chapter 4
IAM Input Connector Pinout
Table 32 - Control Power Connector
Table 33 - DC Bus and Input Power Connector
Table 34 - Contactor Enable Connector
CPD Pin Description Signal
1
Control power VAC input
CTRL 2
2CTRL 1
IPD Pin Description Signal
1
An integral, unregulated power supply, consisting of AC line input,
three-phase bridge rectifier, and filter capacitors.
DC-
2DC+
3 Chassis ground.
4
Three-phase input power.
L3
5L2
6L1
CED Pin Description Signal
1
Relay-driven dry contact used in the control string for a three-
phase power contactor.
CONT EN-
2 CONT EN+
