Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 51
Chapter 3
Mount the Kinetix 6000 Drive System
This chapter provides the system installation procedures for mounting your
Kinetix® 6000 drive components on the Bulletin 2094 power rail.
This procedure assumes you have prepared your panel, mounted your Bulletin
2094 power rail, and understand how to bond your system. For installation
instructions regarding equipment and accessories not included here, refer to
the instructions that came with those products.
Before You Begin
Before you begin, consider your Bulletin 2094 power rail installation and using
2094 mounting brackets.
Using the 2094 Mounting Brackets
You can use Bulletin 2094 mounting brackets to mount the power rail or LIM
module over the AC line filter. Refer to the 2094 Mounting Brackets
Installation Instructions, publication 2094-IN008
, when using mounting
brackets with your Kinetix 6000 drive system.
Topic Page
Before You Begin 51
Determine Mounting Order 52
Mount Modules on the Power Rail 54
SHOCK HAZARD: To avoid hazard of electrical shock, perform all mounting
and wiring of the Bulletin 2094 power rail and drive modules prior to
applying power. Once power is applied, connector terminals can have
voltage present even when not in use.
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep any metal debris from falling into it. Metal debris or other foreign
matter can become lodged in the circuitry, which can result in damage to
components.
