Publication 1785-UM012D-EN-P - July 2005

10-22 Communicating with Devices on a Serial Link

Monitoring Channel 0

Status

The channel 0 status screens display the information stored in the diagnostic

file you specified when you configured channel 0.

Using the System Mode Status Display

This section explains the status data displayed on system mode screens in your

programming software:

System Mode (DF1 Point-to Point) Status Screen

System Mode (DF1 Slave) Status Screen
