Publication 1785-UM012D-EN-P - July 2005
Processor Status File B-9
S:13-S:24
This Word: Stores
S:13 Program file where fault occurred
S:14 Rung number where fault occurred
S:15 VME status file
S:16 I/O status File
S:17Minor fault (word 2)
See also S:10.
S:17/00 BT queue full to remote I/O
S:17/01 Queue full - channel 1A; maximum remote block-transfers used
S:17/02 Queue full - channel 1B; maximum remote block-transfers used
S:17/03 Queue full - channel 2A; maximum remote block-transfers used
S:17/04 Queue full - channel 2B; maximum remote block transfers used
S:17/05 No modem on serial port
S:17/06
• Remote I/O rack in local rack table or
• Remote I/O rack is greater than the image size. This fault can also be
caused by the local rack if the local rack is set for octal density scan
and the I/O image tables are smaller than 64 words (8 racks) each.
S:17/07 Firmware revision for channel pairs 1A/1B or 2A/2B does not
match controller firmware revision
S:17/08 ASCII instruction error
S:17/09 Duplicate node address
S:17/10 DF1 master poll list error
S:17/11 Protected controller data table element violation
S:17/12 Protected controller file violation
S:17/13 Using all 32 ControlNet MSGs
S:17/14 Using all 32 ControlNet 1771 READ and/or 1771 WRITE CIOs
S:17/15 Using all 8 ControlNet Flex I/O CIOs
S:18 Controller clock year
S:19 Controller clock month
S:20 Controller clock day
S:21 Controller clock hour
S:22 Controller clock minute
S:23 Controller clock second
S:24 Indexed addressing offset
S:25 Reserved
