Publication 1785-UM012D-EN-P - July 2005
B-8 Processor Status File
90 Sidecar module extensive memory test failed. Call your Allen-Bradley representative for
service
Recoverable
91 Sidecar module undefined message type
92 Sidecar module requesting undefined pool
93 Sidecar module illegal maximum pool size
94 Sidecar module illegal ASCII message
95 Sidecar module reported fault, which may be the result of a bad sidecar program or of a
hardware failure
96 Sidecar module not physically connected to the PLC-5 controller
97
Sidecar module requested a pool size that is too small for PC
3
command (occurs at power-up)
98 Sidecar module first/last 16 bytes RAM test failed
99 Sidecar module-to-controller data transfer faulted
100 Controller-to-sidecar module transfer failed
101 Sidecar module end of scan transfer failed
102 The file number specified for raw data transfer through the sidecar module is an illegal value
103 The element number specified for raw data transfer through the sidecar module is an illegal
value
104 The size of the transfer requested through the sidecar module is an illegal size
105 The offset into the raw transfer segment of the sidecar module is an illegal value
106 Sidecar module transfer protection violation; for PLC-5/26, -5/46, and -5/86 controllers only
This
Fault
Code
Indicates this Fault And the Fault Is
