Allen-Bradley PLC-5 User Manual

Publication 1785-UM012D-EN-P - July 2005
11-14 Communicating with Devices on an Ethernet Network
The BOOTPTAB files that correspond to this example looks like:
# Legend: gw -- gateways
# ha -- hardware address
# ht -- hardware type
# ip -- host IP address
# sm -- subnet mask
# vm -- BOOTP vendor extensions format
# tc -- template host
#Default string for each type of Ethernet client
defaults5E: ht=1:vm=rfc1048:sm=255.255.255.0
#Entries for Ethernet PLC-5 controllers:
iota1:\
tc=defaults5E:\
gw=130.151.194.1:\
ha=0000BC1C1234:/
ip=130.151.194.19
# Legend: gw -- gateways
# ha -- hardware address
# ht -- hardware type
# ip -- host IP address
# sm -- subnet mask
# vm -- BOOTP vendor extensions format
# tc -- template host
#Default string for each type of Ethernet client
defaults5E: ht=1:vm=rfc1048:sm=255.255.255.0
#Entries for Ethernet PLC-5 controllers:
iota2:\
tc=defaults5E:\
gw=130.151.132.1:\
ha=0000BC1C5678:/
ip=130.151.132.110
# Legend: gw -- gateways
# ha -- hardware address
# ht -- hardware type
# ip -- host IP address
# sm -- subnet mask
# vm -- BOOTP vendor extensions format
# tc -- template host
#Default string for each type of Ethernet client
defaults5E: ht=1:vm=rfc1048:sm=255.255.255.0
#Entries for Ethernet PLC-5 controllers:
iota3:\
tc=defaults5E:\
gw=130.151.138.1:\
ha=0000BC1C9012:/
ip=130.151.138.123
