Publication 1785-UM012D-EN-P - July 2005
System Specifications A-5
Area Description
ControlNet PLC-5 controllers EEPROM memory cannot be loaded to a non-ControlNet PLC-5 controller if the
EEPROM was saved on a ControlNet PLC-5 controller.
EEPROM memory cannot be loaded to a ControlNet PLC-5 controller if the
EEPROM was burned on a non-ControlNet PLC-5 controller.
PLC-5 catalog numbers EEPROM memory can be loaded to a PLC-5 controller if its I/O memory size is
greater than or equal to the I/O memory of the PLC-5 controller from which the
EEPROM was saved. The I/O memory sizes are:
PLC-5/11, -5/204 racks
PLC-5/308 racks
PLC-5/4016 racks
PLC-5/60, -5/8024 racks
EEPROM memory can be loaded to a PLC-5 controller if its user memory is greater
than or equal to the user memory used on the PLC-5 controller from which the
EEPROM was saved. The available user memory is:
PLC-5/118,192 words
PLC-5/2016,384 words
PLC-5/3032,768 words
PLC-5/4065,536 words
PLC-5/80102,400 words
Firmware release compatibility EEPROM memory saved on a series D, revision B PLC-5 controller cannot be
loaded on a PLC-5 controller with an earlier firmware release.
EEPROM memory saved on a series E, revision A PLC-5 controller cannot be
loaded on a PLC-5 controller with an earlier firmware release.
EEPROM memory saved on a series E, revision B PLC-5 controller cannot be
loaded on a PLC-5 controller with an earlier firmware release.
