Allen-Bradley SLC 500 Series - Page 605

Publication 1747-RM001G-EN-P - November 2008
Programming Instruction References D-5
ATN
(2)
Arc Tangent source direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R, N,
F, A, ST, M
-32,768 to 32,767
f-min to f-max
destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R, N,
F, A, ST, M
none
AWA
(1)
ASCII Write with Append channel 0
source direct ST none
control direct R none
string length 0 to 82
characters sent 0 to 82
AWT
(1)
ASCII Write channel 0
source direct ST none
control direct R none
string length 0 to 82
characters sent 0 to 82
BSL Bit Shift Left file indexed direct
indexed indirect
O, I, S, B, N, A, ST none
control direct R none
bit address direct, indirect O, I, S, B, T, C, R, N,
A, ST, M
none
length 0 to 2048
BSR Bit Shift Right file indexed direct
indexed indirect
O, I, S, B, N, A, ST none
control direct R none
bit address direct, indirect O, I, S, B, T, C, R, N,
A, ST, M
none
length 0 to 2048
BTR Block Transfer Read control direct N
source “Data” direct I, O, S, B, N, A, F
buffer direct M1 file address M
BTW Block Transfer Write control direct N
source “Data” direct I, O, S, B, N, A, F
buffer direct M0 file address M
Table D.3 Available Addressing Modes (Continued)
Instruction Description Instruction
Parameter
Valid Addressing
Mode(s)
Valid File Types Immediate
Values
