Allen-Bradley Stratix 8300 User Manual

Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 151
I/O Data Types Appendix A
I:PortFa3_2UnauthorizedDevice BOOL Indicates that an unauthorized MAC ID has attempted to communicate on a particular port
0 = No mismatch
1 = Mismatch
I:PortFa3_3UnauthorizedDevice BOOL
I:PortFa3_4UnauthorizedDevice BOOL
I:PortFa3_5UnauthorizedDevice BOOL
I:PortFa3_6UnauthorizedDevice BOOL
I:PortFa3_7UnauthorizedDevice BOOL
I:PortFa3_8UnauthorizedDevice BOOL
I:AnyPortThreshold BOOL Indicates that unicast, multicast or broadcast threshold limit has been exceeded on any port
I:PortGi1_1Threshold BOOL Indicates that unicast, multicast or broadcast threshold limit has been exceeded
on a particular port
0 = OK
1 = Threshold exceeded
I:PortGi1_2Threshold BOOL
I:PortFa1_1Threshold BOOL
I:PortFa1_2Threshold BOOL
I:PortFa1_3Threshold BOOL
I:PortFa1_4Threshold BOOL
I:PortFa1_5Threshold BOOL
I:PortFa1_6Threshold BOOL
I:PortFa1_7Threshold BOOL
I:PortFa1_8Threshold BOOL
I:PortFa2_1Threshold BOOL
I:PortFa2_2Threshold BOOL
I:PortFa2_3Threshold BOOL
I:PortFa2_4Threshold BOOL
I:PortFa2_5Threshold BOOL
I:PortFa2_6Threshold BOOL
I:PortFa2_7Threshold BOOL
I:PortFa2_8Threshold BOOL
I:PortFa3_1Threshold BOOL
I:PortFa3_2Threshold BOOL
I:PortFa3_3Threshold BOOL
I:PortFa3_4Threshold BOOL
I:PortFa3_5Threshold BOOL
I:PortFa3_6Threshold BOOL
I:PortFa3_7Threshold BOOL
I:PortFa3_8Threshold BOOL
I:AllPortsUtilization SINT The sum of the percentage of the bandwidth utilized of all ports on the switch
I:PortGi1_1Utilization; SINT The percentage of the bandwidth utilized on a particular port
I:PortGi1_2Utilization; SINT
I:PortFa1_1Utilization; SINT
Input Data Types
Tag Name Type Description
