Allen-Bradley Stratix 8300 User Manual

12 Rockwell Automation Publication 1783-UM003G-EN-P - December 2012
Chapter 1 Getting Started
Stratix 8000 and Stratix
8300 Ethernet Managed
Switches and Related
Products
The following table lists the switches and other associated products.
Stratix Switches and Modules
Cat. No. Description
Stratix 8000 Switches (Layer 2)
1783-MS06T 4 10/100BASE-T Ethernet ports and 2 dual-purpose ports, each with a 10/100/1000BASE-T copper port and an SFP
(small form-factor pluggable) module slot
1783-MS10T 8 10/100BASE-T Ethernet ports and 2 dual-purpose ports, each with a 10/100/1000BASE-T copper port and an SFP
(small form-factor pluggable) module slot
Stratix 8300 Switch (Layer 3)
1783-RMS06T 4 10/100BASE-T Ethernet ports and 2 dual-purpose ports, each with a 10/100/1000BASE-T copper port and an SFP
(small form-factor pluggable) module slot
1783-RMS10T 8 10/100BASE-T Ethernet ports and 2 dual-purpose ports, each with a 10/100/1000BASE-T copper port and an SFP
(small form-factor pluggable) module slot
Expansion Modules
1783-MX08T Expansion module with 8 10/100BASE-T copper Ethernet ports
1783-MX08F Expansion module with 8 100BASE-FX fiber optic Ethernet ports
SFP Modules
1783-SFP100FX 100BASE-FX 100 M multi-mode fiber transceiver
1783-SFP1GSX 1000BASE-SX 1 G multi-mode fiber transceiver
1783-SFP100LX 100BASE-LX 100 M single-mode fiber transceiver
1783-SFP1GLX 1000BASE-LX 1 G single-mode fiber transceiver
Power Supplies
Cat. No. Description
1606-XL series (recommended)
1606-XLP series (recommended)
Or equivalent
Class 2, 24V DC output power supplies
CompactFlash Cards
Cat. No. Description
1783-MCF Stratix 8000 CompactFlash card (spare)
1783-RMCF Stratix 8300 CompactFlash card (spare)
Cryptographic IOS
Cat. No. Description
1783-MCS Cryptographic IOS for Stratix 8000 switches
1783-RMCS Cryptographic IOS for Stratix 8300 switches
