152 Rockwell Automation Publication 1783-UM003G-EN-P - December 2012

Appendix A I/O Data Types

I:PortFa1_2Utilization; SINT The percentage of the bandwidth utilized on a particular port

I:PortFa1_3Utilization; SINT

I:PortFa1_4Utilization; SINT

I:PortFa1_5Utilization; SINT

I:PortFa1_6Utilization; SINT

I:PortFa1_7Utilization; SINT

I:PortFa1_8Utilization; SINT

I:PortFa2_1Utilization; SINT

I:PortFa2_2Utilization; SINT

I:PortFa2_3Utilization; SINT

I:PortFa2_4Utilization; SINT

I:PortFa2_5Utilization; SINT

I:PortFa2_6Utilization; SINT

I:PortFa2_7Utilization; SINT

I:PortFa2_8Utilization; SINT

I:PortFa3_1Utilization; SINT

I:PortFa3_2Utilization; SINT

I:PortFa3_3Utilization; SINT

I:PortFa3_4Utilization; SINT

I:PortFa3_5Utilization; SINT

I:PortFa3_6Utilization; SINT

I:PortFa3_7Utilization; SINT

I:PortFa3_8Utilization; SINT

I:MajorAlarmRelay BOOL Indicates whether the major alarm relay is on or off

0 = Contact open (off)

1 = Contact closed (on)

I:MinorAlarmRelay BOOL Indicates whether the minor alarm relay is on or off

0 = Contact open (off)

1 = Contact closed (on)

I:MulticastGroupsActive DINT The number of active multicast groups across all ports

Input Data Types

Tag Name Type Description
