120 Rockwell Automation Publication 1783-UM003G-EN-P - December 2012
Chapter 4 Manage the Switch via RSLogix 5000 Software
Port Thresholds (Storm
Control)
Use this tab to set the threshold limits for broadcast, unicast, and multicast traffic
for each active port. The number of packets being sent is compared against the
threshold value. These limits help to prevent a single device from sending too
much traffic.
Port Thresholds
In this field Values are Comments
Unit • Base (for example, 1783-MS10T).
• Expansion module (for example, 1783-MX08T).
Where the port resides.
