ALMAC BiBi 850-BL - 3.2.2 Ground Controls

BIBI 850-BL Use and maintenance manual Rev.00
42
Sym
bol
I
dentification
Funct
ion
1
Indicator light Planarity alarm:
OF
F= lateral inclination 0°-1°
Longitudinal inclination 0°-1°
ON= l
ateral inclination >1°
Longitudinal inclination >1°
2
Indi
cator light Traction enabling
OF
F= traction not enabled
ON=trac
tion enabled
3
Indicator light Work enabling
OF
F= platform not levelled
FLASHING
= platform levelled/movement at height not
permitted
ON= p
latform level/ movement allowed up to 4.4 m walking
surface
4 Indi
cator light
Overload alarm
5
Return lever Sta
rting/stopping the electric or internal combustion engine
6
3P S
witch
ENGINE position =Standard operation-no line 220V in basket
(w
ith combustion engine running)
ELECT
RIC ENGINE position =switching off the combustion
engine and enabling the electric motor startup with button-7;
activation line 220V at the socket in the basket
OUT 220 position = standard operation-internal combustion
engine active - 220V line in basket active (from inverter)
7
Button Warning buzzer
8
3P S
witch
CENTRAL position = standard operation - traction
FORWARD/REVERSE enabled using 2 joysticks
DC-S
p
osition= Simultaneous movement
FORWARD/REVERSE of both tracks with one single joystick
(11)
ED-S posit
ion = Easy Drive System assisted drive control
system
9
2P Switch
Tortoise position= low speed for all movements
Hare position= high speed for all movements
10
J
oystick
Left track FORWARD/REVERSE movement control
11
J
oystick
Right track FORWARD/REVERSE movement control
12
Return lever
Left platform levelling UP/DOWN
13
Return lever
Righ
t platform levelling UP/DOWN
14
Return lever
Manual length levelling UP/DOWN
15
Return lever
Raise / lower basket with automatic levelling
16
Mushroom button
EM
ERGENCY STOP
