BIBI 850-BL Use and maintenance manual Rev.00
43
3.2.2 Ground controls
Sym
bol
I
dentification
Funct
ion
17
3P Ke
y switch
LEFT position = electrical panel on - mobile pushbutton panel
disabled - ground controls enabled
CENT
RAL position= platform off
RIGH
T position = electrical panel on - ground controls disabled
- mobile pushbutton panel enabled
Button Platform emergency button
Return lever
Return lever Sta
rting/stopping the electric or internal combustion engine
Measurer El
ectronic hour-counter
(
with combustion engine running)
Attention: only personnel who have been properly trained and skilled in using the controls
may use those controls.
IT IS FORBIDDEN to stay inside the basket while another operator performs manoeuvres
with the ground controls.
