ALMAC BiBi 850-BL - Power (Electric) Cut-Out Devices

BIBI 850-BL Use and maintenance manual Rev.00
47
3.3.4 Power (electric) cut-out devices
The basket can be fitted with a 220 V power socket to supply the power tools required during
work. For safety reasons, a device is installed so as to cut-out the electricity supply in case of
over-voltage or short-circuit (2), located inside the right rear casing (pos. 1 in the photo below).
To access the device, unscrew the knobs (3) on the casing and remove the guard. When finished,
replace the guard that was previously removed and thoroughly tighten the knobs.
The battery isolator (4) is located in the same position. It physically disconnects the 12v electric
line coming from the battery and supplies the various users.
BE SURE TO OPERATE THIS DEVICE AT THE END OF THE WORK DAY.
Near the access ladder (see Figure "A") and life-saving devices (figure "B") there are also
security fuses to protect the 12V electrical equipment.
1
2
3
4
