BIBI 850-BL Use and maintenance manual Rev.00
40
3.1.1 Main parts of the machine
1 – Console and handgrip
2 – Opening device for access
3 – Storage compartment
4 - Extensible basket
5 – Extensible structure
6 – Hydraulic lift cylinder
7 – Electrical panel
8 – Hydraulic circuit filters
9 – Hydraulic pumps
10 – Fuel tank
11 – Combustion engine
12 – Hydraulic oil tank
13 - Crawler with side and length levelling (bi-levelling)
14 – Platform frame
15 – Hydraulic valve housing
16 - "Emergency lower" control
17 – Electrical enclosure
18 – Ladder
19 – Locking bar for maintenance
20 – Control panel
21 – Inclinometer
22 - 220v socket
23 - Emergency push-button
24 – Safety microswitches
25 - 220V ac electric motor
26 - Basket extension device
