BIBI 850-BL Use and maintenance manual Rev.00
66
4.2.3 Basket ascent/descent
The basket can be raised using the levers on the control panel. The lifting movement takes place
in the gradual mode established by the manufacturer, while descent is performed at fixed speed.
The platform descent can also be performed with the combustion engine off but the
electrical panel ON.
The ANTI-CRUSHING device will function during this operation, for the purpose of preventing
bystanders near the machine from being injured (see sect.3.3.1 Anti-crushing device).
4.2.3 Manual warning buzzer
Use the push-button on the pushbutton panel to operate the buzzer. It must be used whenever
persons working or moving around the platform area must be warned that platform movements
are in progress.
raise button
d
escent push-button
Warning buzzer
