BIBI 850-BL Use and maintenance manual Rev.00
72
4.4 220 V electrical socket
Voltage characteristics: 220 v – 800 w
Safety: safety device (cut-out)
The power socket (optional) is installed in the basket, alongside the console (see photo below). Its
purpose is to power tools with voltage and power specifications that comply with the indications above.
To enable current to the socket with the combustion engine running, you must turn the switch (6) to
the "OUT-220 V".
With electricity, the socket is usually active.
During operation with the INTERNAL COMBUSTION ENGINE, the 220V socket can be attached to
the plug and the switch (6) can be turned to the OUT 220V position. This makes it possible to use the
electricity in the 220V socket in the basket.
A device automatically disconnects the power supply (cut-out) in the event of a short-circuit and/or
over-voltage.
Po
wer socket 220V Safety switch (cut-out)
2
20v current enabling switch
