Alpha Technologies 100VA eLimiter+ User Manual

SCALE:
REV
SHEET
SIZE
DWG NO.
TITLE:
OF
A
1:1
B
1 1
0300156-06
OUTLINE DRAWING,
SHELF,2U, eLIMITER+
THESE DESIGNS AND SPECIFICATIONS ARE
CONFIDENTIAL, REMAIN THE PROPERTY OF
ALPHA TECHNOLOGIES LTD., AND SHALL NOT BE
COPIED OR USED WITHOUT ITS WRITTEN CONSENT
© ALPHA TECHNOLOGIES LTD
CHECKED DRAWN
DATE
APPROVALS
H.Wu
FEB-28-14 FEB-28-14
ZL
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIM ARE IN MM
INTERPRET DIM AND TOL PER
ASME Y14.5M-1994
X X.X X.XX ANGULAR:
1
1
0.5
0.25
CXCI+ CONTROLLER (OPTIONAL)
eLIMITER+ MODULE (SOLD SEPARATELY)
433.8 17.08
433.8 17.08
16.7 0.66
129.7 5.10
OFFSET
88.6 3.49
464
18.25
19" RACK MOUNT
565.3 22.25
23" RACK MOUNT
347.9 13.70
REVISIONS
LTR
DESCRIPTION
DWN
DATE
CHK
A
INITIAL RELEASE
ZL
FEB-27-14
H.Wu
A B C
D
E
123
4
5
D
A C
E
B
13
5
4
2
DO NOT SCALE DRAWING
