Alpha Technologies 100VA eLimiter+ User Manual

SCALE:
REV
SHEET
SIZE
DWG NO.
TITLE:
OF
A
1:4
B
1 1
0300156-08
CUSTOMER CONNECTIONS
DRAWING, eLIMITER+
THESE DESIGNS AND SPECIFICATIONS ARE
CONFIDENTIAL, REMAIN THE PROPERTY OF
ALPHA TECHNOLOGIES LTD., AND SHALL NOT BE
COPIED OR USED WITHOUT ITS WRITTEN CONSENT
© ALPHA TECHNOLOGIES LTD
CHECKED DRAWN
DATE
APPROVALS
H.Wu
FEB-2814 OCT-15-13
ZL
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIM ARE IN MM
INTERPRET DIM AND TOL PER
ASME Y14.5M-1994
X X.X X.XX ANGULAR:
1
1
0.5
0.25
F
REAR
COMMON
B (HOT) A (HOT)
REAR INPUTS (FOR 1/4" x 0.625" TWO HOLE LUGS)
COMMON B (HOT) A (HOT)
RIGHT SIDE
(REAR INPUT COVER TRIMMED)
A
B
C
D
E
CHASSIS GROUNDS (FOR #10-24 X 0.625" TWO HOLE LUGS)
LEFT SIDE
DETAIL A
SCALE: 1 : 1
NO
C
NC
DETAIL B
SCALE: 1 : 1
NO
C
NC
FORM C RELAY
DETAIL C
SCALE: 1 : 1
SHELF ID ROTARY SELECTOR
DETAIL D
SCALE: 1 : 1
FAN POWER CONNECTOR FOR OPTIONAL FAN TRAY
DETAIL E
SCALE: 1 : 1
CAN CONNECTORS
DETAIL F
SCALE: 1 : 1
SWITCH TO GANG ADJACENT MODULES
DETAIL G
SCALE: 1 : 2
REAR OUTPUTS
CONNECT 12AWG WIRE MAXIMUM
THESE 4 OUTPUTS CONNECTED TO INPUT B
THESE 5 OUTPUTS CONNECTED TO INPUT A
FRONT INPUTS (FOR 1/4" x 0.625" TWO HOLE LUGS)
FORM C RELAY
REVISIONS
LTR
DESCRIPTION
DWN
DATE
CHK
A
INITIAL RELEASE
ZL
FEB-28-14
H.Wu
A B C
D
E
123
4
5
D
A C
E
B
13
5
4
2
DO NOT SCALE DRAWING
