Alpine iLX-507E - Specifications; Monitor, Tuner, and USB Specifications

ALPINE iLX-F509E 68-41657Z84-A (EN)ALPINE iLX-F509E 68-41657Z84-A (EN)
60-EN
Specifications
MONITOR SECTION
Screen Size 7” (iLX-507E)
9” (iLX-F509E)
11” (iLX-F511E)
Operation System TFT active matrix
Number of Picture Elements
2,764,800 pcs. (1280 × 720 × RGB)
Effective Number of Picture Elements
99% or more
Color system NTSC / PAL
Illumination System LED
FM TUNER SECTION
Tuning Range 87.5 – 108.0 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 μV/75 ohms)
50 dB Quieting Sensitivity
13.5 dBf (1.3 μV/75 ohms)
Alternate Channel Selectivity
80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
AM TUNER SECTION
Tuning Range 531 – 1,602 kHz
Usable Sensitivity 25.1 μV/28 dBf
USB1 SECTION
USB requirements USB 2.0
Max. Power Consumption
2,400 mA
USB Class USB (Mass Storage Class)
File System FAT16/32, exFAT
Number of Channels 2-Channels (Stereo)
Frequency Response* 1 5 – 40,000 Hz (±1 dB)
Total Harmonic Distortion
0.005% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 95 dB
Channel Separation 90 dB (at 1 kHz)
*1 Frequency response may differ depending on the
encoder software/bit rate.
USB2 SECTION
Max. Power Consumption
1,500 mA (CDP Support)
USB Class Charge only
HDMI SECTION
Input Format 720p / 480p / VGA
Output Format 720p / 480p
Bluetooth SECTION
Bluetooth Specification Bluetooth V4.2 (2,402 - 2,480 MHz)
Output Power +4 dBm Ave. (Power class 2)
Profile HFP (Hands-Free Profile)
OPP (Object Push Profile)
PBAP (Phone Book Access Profile)
SPP (Serial Port Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
GPS SECTION
Reception Frequency 1575.42 + / - 1.023 MHz
Reception sensitivity (Search) -136 dB max.
Wi-Fi SECTION
Frequency Ranges IEEE 802.11 b/g/n (2.4 GHz)
Channels 1 – 13 ch (2.4 GHz)
Security Protocols WPA3 / WPA2-PSK (TKIP, AES)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Operating temperature -20°C to + 60°C
Power Output 50 W × 4
Maximum Current Consumption
15 A
Audio output level
Preout (Front, Rear): 4V/10k ohms (max.)
Preout (Subwoofer): 4V/10k ohms (max.)
Weight 1.4 kg (iLX-507E)
2.3 kg (iLX-F509E)
2.6 kg (iLX-F511E)
CHASSIS SIZE
iLX-507A iLX-F509E iLX-F511E
Width 178 mm 178 mm 178 mm
Height 50 mm 50 mm 50 mm
Depth 149.6 mm 149.6 mm 149.6 mm
iLX-507A iLX-F509E iLX-F511E
171 mm 232.5 mm 268.9 mm
96 mm 151.1 mm 178 mm
17.7 mm 54.7 mm 54.7 mm
ntinuous product improvement, specifications and
ubject to change without notice.
anel is manufactured using an extremely high
anufacturing technology. Its effective pixel ratio is
is means that there is a possibility that 0.01%
els could be either always ON or OFF.
