4.17.2 Auto Channel Selection
By default, the Auto Channel Selection is disabled; the A2 is fixed on Channel 6. When
Enabled of Auto Channel Selection is chosen, A2 can scan all available radio channels which
are assigned to the regulatory domain. The “cleanest” channel is then selected as the operating
channel.
NOTE: After changing frequency channel, it takes around 3 minutes for A2 to
optimize its radio performance.
4.17.3 Maximum Clients
A value between the ranges from 0 to 256 can be filled in Maximum Clients blank. This feature
can limit the total associated clients under the particular radio.
4.17.4 Transmit Power
The value of the Transmit Power depends on both the gain of the antenna and the maximum
value of the Effective Isotropic Radiated Power (Max EIRP) allowed based on Regulatory
Domain. The Transmit Power should be configured within the given range as shown in Figure
16. The Tx Power could be set from 10 to 26 dBm for 2.4GHz radio, and Tx Power range for
5GHz radio is from 10 to 23 dBm.
NOTE: Click the Update icon to store the changed settings.
4.17.5 Advanced Radio Setting
More radio parameters can be verified and altered by selecting the Advanced icon in the field of
Advanced Setting. The parameters are shown in Figure 1. The following table showed is the best
suggested interval worked with the current operated APs. Note that it is not suggested to change
the parameters in Advanced Radio Settings unless you are experienced administrators.
