In 802.11na HT40ext ch-1:
Users can select a 5GHz channel in the pool from channel 56 to 64 (5.28GHz to 5.32GHz),
104 to 136 (5.52GHz to 5.68GHz) and 153 to 161 (5.765GHz to 5.805GHz).
For RoW:
In 802.11a mode:
User can select a 5GHz channel in the pool from channel 36 to 64 (5.18GHz to 5.32GHz),
100 to 140 (5.5GHz to 5.7GHz) and 149 to 173 (5.745GHz to 5.865GHz).
In 802.11na HT20:
User can select a 5GHz channel in the pool from channel 36 to 64 (5.18GHz to 5.32GHz),
100 to 140 (5.5GHz to 5.7GHz) and 149 to 173 (5.745GHz to 5.865GHz).
In 802.11na HT40ext ch+1:
Users can select a 5GHz channel in the pool from channel 36 to 60 (5.18GHz to 5.3GHz),
100 to 132 (5.5GHz to 5.66GHz) and 149 to 157 (5.745GHz to 5.785GHz).
In 802.11na HT40ext ch-1:
Users can select a 5GHz channel in the pool from channel 40 to 64 (5.2GHz to 5.32GHz),
104 to 136 (5.52GHz to 5.68GHz) and 153 to 161 (5.765GHz to 5.805GHz).
4.20.4 Bridge Radio Transmit Power
The power for 5GHz Radio is set in this area. The value of the Transmit Power depends on both
the gain of the 5GHz antenna and the Max EIRP allowed by the country in which A2 is used.
The Transmit Power can be configured within the given range (10 - 23dBm).
NOTE: Click the Update icon to store the Transmit Power settings.
4.20.5 Advanced Radio Setting
More radio parameters can be verified and altered by selecting the Advanced icon in the field of
Advanced Setting. The parameters are shown in Figure 2431.
