5GHz Radio Mode
Data Rate
Channels
802.11a
54 Mbps
52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124,
128, 132, 136, 140, 149, 153, 157, 161
802.11na HT20
130 Mbps
52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124,
128, 132, 136, 140, 149, 153, 157, 161
802.11na HT40ext ch+1
300 Mbps
52, 60, 100, 108, 116, 124, 132, 149, 157
802.11na HT40ext ch-1
300 Mbps
56, 64, 104, 112, 120, 128, 136, 153, 161
Table 8 5GHz Radio channel and Data Rate for FCC
5GHz Radio Mode
Data Rate
Channels
802.11a
54 Mbps
36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112,
116, 120, 124, 128, 132, 136, 140, 149, 153, 157,
161, 165, 169, 173
802.11na HT20
130 Mbps
36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112,
116, 120, 124, 128, 132, 136, 140, 149, 153, 157,
161, 165, 169, 173
802.11na HT40ext ch+1
300 Mbps
36, 44, 52, 60, 100, 108, 116, 124, 132, 149, 157
802.11na HT40ext ch-1
300 Mbps
40, 48, 56, 64, 104, 112, 120, 128, 136, 153, 161
Table 9 5GHz Radio channel and Data Rate for RoW
For ETSI:
In 802.11a mode:
User can select a 5GHz channel in the pool from channel 36 to 64 (5.18GHz to 5.32GHz)
and 100 to 140 (5.5GHz to 5.7GHz)
In 802.11na HT20:
User can select a 5GHz channel in the pool from channel 36 to 64 (5.18GHz to 5.32GHz)
and 100 to 140 (5.5GHz to 5.7GHz)
In 802.11na HT40ext ch+1:
Users can select a 5GHz channel in the pool from channel 36 to 60 (5.18GHz to 5.3GHz)
and 100 to 132 (5.5GHz to 5.66GHz)
In 802.11na HT40ext ch-1:
Users can select a 5GHz channel in the pool from channel 40 to 64 (5.2GHz to 5.32GHz)
and 104 to 136 (5.52GHz to 5.68GHz)
For FCC:
In 802.11a mode:
User can select a 5GHz channel in the pool from channel 52 to 64 (5.26GHz to 5.32GHz),
100 to 140 (5.5GHz to 5.7GHz) and 149 to 161 (5.745GHz to 5.825GHz).
In 802.11na HT20:
Users can select a 5GHz channel in the pool from channel 52 to 64 (5.26GHz to 5.32GHz),
100 to 140 (5.5GHz to 5.7GHz) and 149 to 161 (5.745GHz to 5.825GHz).
In 802.11na HT40ext ch+1:
Users can select a 5GHz channel in the pool from channel 52 to 60 (5.26GHz to 5.3GHz),
100 to 132 (5.5GHz to 5.66GHz) and 149 to 157 (5.745GHz to 5.785GHz).
