IS-200A
4. How to Operate Screens
4-4
<Secondary constant-power
effective value control ms mode>
<Secondary constant-power
effective value control CYC mode>
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 0000 0000 000 000 00000 0000ms
UP WELD DOWN HEAT
1 000 000 000 ms 1.00kW
2 000 000 000 ms 1.00kW
3 000 000 000 ms 1.00kW
PAGE DOWN  HEAT CTRL2:<POWER RMS >
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 000 000 00 00 000 00 CYC
UP WELD DOWN HEAT
1 00 00 00 CYC 1.00kW
2 00 00 00 CYC 1.00kW
3 00 00 00 CYC 1.00kW
PAGE DOWN  HEAT CTRL2:<POWER RMS >
<Primary constant-current
peak value control ms mode>
<Primary constant-current
peak value control CYC mode>
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 0000 0000 000 000 00000 0000ms
UP WELD DOWN HEAT
1 000 000 000 ms 1.00kA
2 000 000 000 ms 1.00kA
3 000 000 000 ms 1.00kA
PAGE DOWN  HEAT CTRL3:<PRIMARY LIMIT>
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 0000 0000 000 000 000 00 CYC
UP WELD DOWN HEAT
1 00 00 00 CYC 1.00kA
2 00 00 00 CYC 1.00kA
3 00 00 00 CYC 1.00kA
PAGE DOWN  HEAT CTRL3:<PRIMARY LIMIT>
<Secondary constant-voltage
effective value control ms mode>
<Secondary constant-voltage
effective value control CYC mode>
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 0000 0000 000 000 00000 0000ms
UP WELD DOWN HEAT
1 000 000 000 ms 0.20V
2 000 000 000 ms 0.20V
3 000 000 000 ms 0.20V
PAGE DOWN  HEAT CTRL4:<VOLTAGE RMS >
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 000 000 00 00 000 00 CYC
UP WELD DOWN HEAT
1 00 00 00 CYC 0.20V
2 00 00 00 CYC 0.20V
3 00 00 00 CYC 0.20V
PAGE DOWN  HEAT CTRL4:<VOLTAGE RMS >
<Constant-phase control ms mode> <Constant-phase control CYC mode>
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 0000 0000 000 000 00000 0000ms
UP WELD DOWN HEAT
1 000 000 000 ms 10.0 %
2 000 000 000 ms 10.0 %
3 000 000 000 ms 10.0 %
PAGE DOWN  HEAT CTRL5:<FIXED PULSE >
-SCHEDULE #001 WELD ON/OFF OFF
SQD SQZ COOL1 COOL2 HOLD OFF
TIME 000 000 00 00 000 00 CYC
UP WELD DOWN HEAT
1 00 00 00 CYC 10.0 %
2 00 00 00 CYC 10.0 %
3 00 00 00 CYC 10.0 %
PAGE DOWN  HEAT CTRL5:<FIXED PULSE >
