IS-200A
10. External Communication Function
10-10
Item Contents
Character
String
Range
11 WELD COUNT n,
0: OFF
1: ON
12 RE-WELD n,
0: OFF
1: ON
13 WELD TIME n,
0: ms
1: CYC
14 WELD COUNT nnnn, 0000 to 9999
15 NO CURRENT TIME nn, 01 to 99 (ms)
16 NO CURRENT LEVEL n.nn, 0.00 to 9.99 (kA)
17 NO VOLTAGE LEVEL n.nn, 0.00 to 9.99 (V)
18 MONITOR FIRST TIME nn, 00 to 15 (ms)
19 MONITOR SLOPE MODE n,
0: EXCLUDE
1: INCLUDE
20
CURRENT MONITOR
NUMBER
n, 1 to 3
21 SCAN MODE n,
0: OFF
1: 1-1
2: 1-2
3: 1-3
4: 1-4
5: 1-5
22* PROGRAM PROTECT n
0: OFF
1: ON
* Items inhibited from setting (When setting data, omit these items.)
Screen 06 (Error data)
Common data (Schedule No.: 000)
Error data confirmation (Data reading only)
Item Contents
Character
String
Range
1 Error code 1 nnn, E01 to E31
2 Error code 2 nnn, E01 to E31
3 Error code 3 nnn, E01 to E31
4 Error code 4 nnn, E01 to E31
5 Error code 5 nnn E01 to E31
The number of Error Codes is of five max. In the case of only one error code, the
items 2 to 5 are omitted.
For Error Codes, see 12. (1) Fault Code List.
Error reset (Data setting only)
Item Contents
Character
String
Range
1 Error reset nnn E00
