36 LS User Manual
The Default test setups are as follows:
Test name > LIMIT_TEST CYCLE_TEST BREAK_TEST NEW_TEST
Test Type Settings
Test mode Tension Tension Tension Tension
Test type Limit Cycling Limit Limit
Limit position 10.0mm 10.0mm N 10.0mm
Home position 0.0mm
No. of cycles 10
Preload 0.0N 0.0N 0.0N 0.0N
Speed 100mm/min 100mm/min 25mm/min 250mm/min
Hold 0 seconds 0 seconds
Machine Stiffness Disabled Disabled Disabled Disabled
Compensation
Test Options
Sharp Break detector off off on off
% Break Detector off off off off
Return to zero manual Manual manual Manual
Zero readings manual Manual manual Manual
Sample printout All All All All
Extensometer Used Internal Internal Internal Internal
Test Results
Peak Load N N N N
Extens’n at peak load mm mm mm Mm
Break load N N N N
Extension at Br’k load mm mm mm Mm
Pass/fail Checks off off off off
Dene Sample
Sample type Rectangular Rectangular Rectangular Rectangular
Gauge 25.00mm 25.00mm 25.00mm 25.00mm
Width 6.00mm 6.00mm 6.00mm 6.00mm
Thickness 3.00mm 3.00mm 3.00mm 3.00mm
1st Batch ? line 1 OPERATOR OPERATOR OPERATOR OPERATOR
1st Batch ? line 2 NAME NAME NAME NAME
2nd Batch ? line 1 BATCH BATCH BATCH BATCH
2nd Batch ? line 2 NUMBER NUMBER NUMBER NUMBER
3rd Batch ? line 1
3rd Batch ? line 2
Sample ? line 1 SAMPLE SAMPLE SAMPLE SAMPLE
Sample ? line 2 ID ID ID ID
Batch questions off off off off
Sample questions off off off off
