44 LS User Manual
Sharp Percent Start Break
Break Break 50 Point
Off On N 50 %
Sharp Percent Start
Break Break 50
On Off N
Plotter
Output
disabled >
Press a key to change a parameter
By pressing the Break Detector Soft Key the following display is shown
Sharp Break Detector
Press a key to change a parameter
There are two break detectors, a sharp break detector and a percentage of peak load break detector.
The sharp break detector operates when there has been a sharp change in load or direction between
one load reading and the next. Either break detector is turned On or Off by pressing the appropriate
Soft Key. Only one break detector can be turned On at a time. When a break detector is turned On,
other options are displayed. Both break detectors have a Start option and the Percentage break
detector also has a Percentage Break option.
Percentage of Peak Load Break detector
Press a key to change a parameter
The Start option sets the threshold above which the peak load must rise before the break detector
will start operation. The Percent Break option sets the percentage of peak load below which the
measured load must fall to constitute a break.
The Return and Zero options toggle between Manual and Auto.
To Next Page
