Overview Sorensen SGI Series
1-2 M550221-01 Rev U
For units up to 999 V/999 A, voltage and current are represented in numeric format, e.g., “100”
represents 100 V. For units at 1000 V/1000 A and above, the voltage and current are
represented by the format xKx”, e.g., “1K0” represents 1000 V.
Option
Description
Control Options
A: Analog
I: Intelligent
Input Options
C: Input Voltage 208/230 VAC, 3-Phase
D: Input Voltage 380/400 VAC, 3-Phase
E: Input Voltage 440/480 VAC, 3-Phase
Remote Control
Options
0A: No Option
1A: IEEE-488.2 + RS-232C
1C: Ethernet + RS-232C
1D: Isolated Analog Interface
1E: Shaft Locks
2A: Combined Options 1A + 1D
2C: Combined Options 1A + 1E (SGA Only)
2G: Combined Options 1C + 1D
2H: Combined Options 1C + 1E (SGA Only)
2J: Combined Options 1D + 1E (SGA Only)
3C: Combined Options 1A + 1D + 1E (SGA Only)
3G: Combined Options 1C + 1D + 1E (SGA Only)
Process Options
AA: No option
AB: Certificate of Calibration (includes test data)
Modifications
AJ: Front panel dust filter (3U models only)
CV: 400Hz AC input at 208 VAC for 6U units only; does not
carry CE, CSA or UL certification; (standard in 3U models)
PF: Passive power factor correction to 0.9 for 40V to 800V
models; (standard in 10V-30V, 50V, and 1000V models)
Figure 1-1. Model Number Decoding
SG I 100 X 100 C - 1A AA AJ
Control Designation
A = Analog
I = Intelligent
Voltage
4-15 kW = "X"
20-30 kW = "/"
Current
Modifications
Process Options
Remote Control Options
Input Voltage Options
