M550221-01 Rev U 2-1
SECTION 2
INSTALLATION
2.1 Inspection
Inspect the shipping carton for possible damage before unpacking the unit.
Carefully unpack the equipment. Save all packing materials until inspection is
complete. Verify that all items listed on the packing slips have been received.
Visually inspect all exterior surfaces for broken knobs, connectors, or meters.
Inspect for dented or damaged exterior surfaces. External damage may be an
indication of internal damage. If any damage is evident, immediately contact
the carrier that delivered the unit and submit a damage report. Failure to do so
could invalidate future claims. Direct repair issues to Customer Service at 858-
458-0223 (local) or 1-800-733-5427 (toll free in North America).
2.2 Contents of Shipment
Depending on the model, configuration, and options available for your SGI
Series power supply, the ship kit may include additional parts and accessories.
Minimum items included in the ship kit:
AMETEK manuals CD-ROM (P/N M550008-01) containing the SGI Series
DC Power Supplies Operation Manual (this manual, P/N M550221-01),
and the SG manual for the digital interface options, IEEE 488.2/RS232
and Ethernet Programming Manual (P/N M550129-03).
Sense mating connector:
10V-800V models, (Molex P/N 39-01-4031) with loose contacts (Molex P/N 39-
00-0182)
1000V model, (Molex P/N 39-01-4041) with loose contacts (Molex P/N 39-01-
0182)
J1 mating connector (Cinch P/N DB25P or equivalent) normally
shipped attached to rear panel J1
Backshell for J1 (DB25) mating connector (Cinch P/N DCH-B-001 or
equivalent)
