Sorensen SGI Series Installation
M550221-01 Rev U 2-11
2.7 Outline Drawings
Figure 2-2 through Figure 2-5 show the outlines and overall dimensions for
installation of the 3U and 6U models of the SGI Series power supplies.
Figure 2-6 through Figure 2-14 show locations of rear panel connectors.
Figure 2-15 shows protective covers for the AC input and DC output of the 3U
10V-30V models.
