Installation Sorensen SGI Series
2-6 M550221-01 Rev U
Feed-Through terminal block with
compression terminals
Bus Bar with holes for 1/4"–20 bolts
Table 2–4. Input Terminal Connections
CAUTION!
To prevent damage to the AC input connector of the 3U units, follow torque
specifications, and, if a wire ferrule is used, ensure that it is properly sized
and that it has been crimped with the appropriate ferrule crimping tool.
AC Input Connector for 3U Models
Recommended torque for the AC input connector screws: 17.7 in-lb to 20.4 in-
lb (2 Nm to 2.3 Nm).
Wire ferrules are recommended, properly sized to match the wire gauge; use
appropriate crimp tool for the ferrule size.
Wire insulation should be stripped to 5/8”, maximum.
For more information on the AC input connector, refer to the manufacturer
(Phoenix Contact) part number HDFKV 16 at their website,
www.phoenixcontact.com.
4 kW to 15 kW, 10V-30V models
Bus bars with two holes for 1/2” bolts on each terminal
(POS. and NEG.)
5 kW to 15 kW, 40V-1000V models
40V-600V models: bus bars with single holes for 3/8" bolts
on each terminal (POS. and NEG.)
800V and 1000V models: 1/4-20 studs for each terminal
(POS. and NEG.)
Bus bars with single holes for 3/8" bolts for each terminal
(POS. and NEG.)
Table 2–5. Output Terminal Connections
P, PV, or PN series, or
equivalent
Standard stranded wire: LCA Series, or equivalent
Flexible stranded wire: LCAX Series, or equivalent
Note:
Contact lug manufacturer for recommended crimping tool.
Table 2–6. Recommended Lugs
Table 2–7. Recommended Sense Connector Tools
