Ametek Sorensen SGI Series User Manual

Operation Sorensen SGI Series
3-6 M550221-01 Rev U
Item
Reference
Functional Description
1
AC Input Connectors
Connection for 3-phase AC.
2
AC Input Safety Ground
Connection for safety ground wire.
3
DC Output Bus Bars
Positive (+) and negative (–) outputs.
3a
HV DC Output Studs
Positive (+) and negative (–) outputs for 800V and
1000V models only.
4
PAR OUT
Parallel Out connector of master unit for configuring
parallel operation of units when connected to Parallel In
connector of slave unit; see Section 3.16 .
5
PAR IN
Parallel In connector of slave unit for configuring parallel
operation of units when connected to Parallel Out
connector of master unit; see Section 3.16.
6
ANALOG CONTROL
Remote Analog Interface connector, J1, for
programming and monitoring signals of output, status
indication, and remote shutdown signals; see Table 3–5
for individual pin descriptions.
7
SENSE Connector
Input connector, J3, for remote sensing of voltage at the
load to compensate for line drop in load cables; see
Section 3.14.
7a
HV SENSE Connector
Input connector,J3, for remote sensing of voltage at the
load to compensate for line drop in load cables, 800V
and 1000V models only; see Section 3.14.
8
RS-232 Connector
†
RS-232 connector for remote digital control.
9
Configuration Switch
†
Eight-position DIP switch to configure the digital
interface of the unit
Refer to Figure 3-2, Figure 3-5, and Figure 3-8Error! Reference source not found..
†
Refer to the Programming Manual for details on the digital interface.
Table 3–2. Rear Panel Connectors and Controls, Standard
