Overview Sorensen SGI Series
1-8 M550221-01 Rev U
1.2.4 Physical Characteristics
Dimensions
3U Models,
10V-30V
3U Models,
40V-1000V
6U Models,
60V-600V
Width
19.00 in (48.26 cm)
19.00 in (48.26 cm)
19.00 in (48.26 cm)
Depth
From inner surface of front panel to maximum protrusion of protective covers at
rear panel; refer to installation drawings for chassis dimensions.
28.09 in (71.35 cm)
25.46 in (64.67 cm)
27.18 in (69.04 cm)
Height
5.25 in (13.34 cm)
5.25 in (13.34 cm)
10.5 in (26.67 cm)
Weight
(nominal)
65 lb (29 kg), (4 kW, 10V, 15V)
65 lb (29 kg), (5 kW, 20V, 30V)
85 lb (39 kg), (8 kW, 10V, 15V)
85 lb (39 kg), (10 kW, 20V, 30V)
110 lb (50 kg), (12 kW, 10V, 15V)
110 lb (50 kg), (15 kW, 20V, 30V)
40 lb (18 kg), (5 kW)
60 lb (27 kg), (10 kW)
80 lb (36 kg), (15 kW)
120 lb (54 kg), (20 KW)
140 lb (64 kg), (25 kW)
160 lb (73 kg), (30 kW)
Shipping
Weight
Contact factory for weights of specific models
