Operation Sorensen SGI Series
3-32 M550221-01 Rev U
Use the NavPad to change to the next step (TEST01-6). Select the V/I
Mode operation and set the OVP to 60 V, voltage to 0 V, current to 10
A and time duration to 2 s.
Step 7 – Go to sequence 2
Use the NavPad to change to the next step (TEST01-7). Select the
Goto operation and set the next step to TEST02. Press the ESC or
Menu key to move to the Save Sequence screen and press F1 for Yes.
Sequence 2 – On/Off Loop
From the Home Menu Page 1, select F3 to enter the main Sequence
Menu. Use the Navigation arrows to select the sequence labeled
TEST02. Press F4 (Del Test) to reset all steps in TEST02 to a NOP
condition. Press F3 to enter the Sequence Step menu.
Step 1 – Begin a loop and set the count to 5
Use the NavPad to change to the first step (TEST02-1). Select the
Loop operation and set the count to 5.
Step 2 – Turn on the voltage to 40 V for 2 s
Use the NavPad to change to the next step (TEST02-2). Select the V/I
Mode operation and set the OVP to 60 V, voltage to 40 V, current to
10A and time duration to 2 s. Press F1 to copy this step to the copy
buffer.
Step 3 – Turn off the voltage for 2 seconds
Use the NavPad to change to the next step (TEST02-3). Press the F2
key to paste the previously saved step into this step. Set the voltage
to 0 V, all other settings remain the same.
Step 4 – Execute the Next loop until all 5 are complete
Use the NavPad to change to the next step (TEST02-4). Select the
Next operation.
Step 5 – Stop the sequence
Use the NavPad to change to the next step (TEST02-5). Select the
Stop operation. Press the ESC or Menu key to move to the Save
Sequence screen and press F1 for Yes.
This completes programming of the sequences.
To run this sequence, from Home Menu Page 1, press F3 to enter the main
Sequence menu. Select TEST01 test sequence and press F1 to start the
sequence. The display will show progress of the sequence and should
complete in approximately 30 s.
