2.1 Identification of the roller
2.1.1 Machine types
The data given below serve to identify the models. The machine models differ only
in terms of weight and the width of the roller drum. The combined roller has a pneu-
matic wheel axis instead of the smooth back drum roller.
ARX 36
ARX 40
ARX 45
Tab. 2-1 Roller with roller drum
ARX 40 K
ARX 45 K
Tab. 2-2 Roller with pneumatic wheel (combined roller)
Model Roller drum width Weight
ARX 36 1300 mm 3740kg
ARX 40 1300 mm 4125kg
ARX 45 1380 mm 4670kg
Model Roller drum width Weight
ARX 40 K 1300mm 3840kg
ARX 45 K 1380mm 4070kg
