Ammann ARX 45 - Replacing the Bulb; Roof

74 ARX 4
1208531 | 03.07.2012
Fig. 8-4 Revolving warning light in operation / not in operation
8.4.3 Replacing the bulb
1 Unscrew the theft-protection screw (1).
2 Lift the cover off with a twisting motion toward the right (2).
3 Press the two lugs of the bulb holder (3) together.
4 Remove the bulb from the holder.
5 Pull the bulb out of the connector.
6 Replace the defective bulb with a new one of the same type and wattage.
Fig. 8-5 Replacing the bulb
NOTE Do not touch the glass of the new bulb with your fingers. Sweat on your hands
can burn into the glass and reduce bulb lifetime.
8.5 Roof
The roof option serves as all-weather protection. You can use the roof to protect from
sun and rain.
1
2
3
