Ammann ARX 45 - Draining Engine Oil

Maintenance 97
1208531 | 03.07.2012
Fig. 9-11 Filler neck to the left and filler neck on top.
NOTE In order to guarantee operating safety of the engine for the long term, you must
not put any additives in the engine oil.
9.9.3 Draining engine oil
The engine oil drain is located at the front left, between the front and rear chassis.
1 Turn the roller all the way to the right. This provides easier access to the
engine oil drain (1).
Fig. 9-12 Roller turned fully / Engine oil drain
2 Place a container under the drain.
3 Open the union by turning it anti-clockwise (27mm wrench).
a
b
CAUTION
Environmental hazard through operating materials!
• Do not allow any liquids get into drains, soil or the environment.
1
1
!
